Giriş
The SIMREX Robot Dog RC Stunt Car is an advanced robotic companion designed for dynamic play. Featuring an innovative 8-wheel Mecanum system, RGB LED eyes, and dual control options, this toy offers unparalleled mobility and interactive experiences. It is suitable for ages 6 and up.
Əsas Xüsusiyyətlər:
- Dynamic 8-wheel Mecanum system for 360° mobility.
- Auto-changing RGB LED eyes for expressive interaction.
- Dual control system: ergonomic 2.4GHz remote controller and gesture-sensing wristband.
- 8 dynamic action modes with three interactive sound effects.
- One-touch demo button for impressive stunt sequences.
- Premium durability with industrial-grade Mecanum wheels and high-traction rubber treads.
- Dual 500mAh Li-ion batteries for extended runtime and quick USB recharging.
Təhlükəsizlik Məlumatı
WARNING: Small Parts. Not for children under 3 years.
- Oyun zamanı həmişə uşaqlara nəzarət edin.
- Su yaxınlığında və ya nəm şəraitdə işləməyin.
- Avoid operating in crowded areas to prevent collisions.
- Məhsulu sökməyin və ya dəyişdirməyin.
- Batareyaların düzgün qütblü şəkildə daxil edildiyinə əmin olun.
- Remove batteries from the toy and remote control when not in use for extended periods.
Qutuda nə var
Your SIMREX Robot Dog RC Stunt Car package includes the following components:
- 1 x Eight-Wheel Robot Dog
- 1 x 2.4 GHz Uzaqdan İdarəetmə
- 2 x 3.7V 800mAh Li-ion batareyaları
- 1 x Remote Control Switch (Gesture-sensing wristband)
- 1 x Operation Guide (User Manual)
- 1 x Tornavida
- 1 x USB şarj kabeli
Quraşdırma Bələdçisi
1. Batareyanın quraşdırılması
Robot Dog: Use the included screwdriver to open the battery compartment on the robot dog. Insert one of the 3.7V 800mAh Li-ion batteries, ensuring correct polarity. Close the compartment securely.
Uzaqdan İdarəetmə: Open the battery compartment on the back of the 2.4GHz remote control. Insert 2 x AA batteries (not included), observing polarity. Close the compartment.
Gesture-Sensing Wristband: The wristband typically has a built-in rechargeable battery. Refer to the charging instructions below.
2. Charging the Robot Dog Battery
Connect the 3.7V 800mAh Li-ion battery to the USB charging cable. Plug the USB cable into a standard USB power adapter (e.g., computer USB port, wall adapter). The indicator light on the USB cable will show charging status. Charging typically takes approximately 60-90 minutes for a full charge. Do not overcharge.
3. Açma və qoşma
Turn on the robot dog using the power switch. Turn on your preferred controller (remote control or gesture-sensing wristband). The robot dog and controller will automatically pair via 2.4GHz wireless technology. A successful connection is usually indicated by a steady light on both devices.
Əməliyyat Təlimatları
1. Uzaqdan İdarəetmə Əməliyyatı
The ergonomic remote control allows for precise movements. Use the joysticks and buttons to control the robot dog's direction, speed, and special functions. Refer to the diagram below for button functions.
- Sol Joystick: Controls forward/backward movement and turning.
- Sağ Joystick: Controls sideways movement and rotation.
- Funksiya Düymələri: Activate specific stunts, sound effects, and LED eye changes.
- One-Key Demo: Press to activate pre-programmed stunt sequences.
2. Gesture Sensing Wristband Operation
Wear the wristband on your hand. The robot dog will respond to your hand gestures, allowing for hands-free control. Tilt your hand forward, backward, left, or right to control movement. Specific gestures may activate stunts or modes.
3. Dynamic Action Modes and LED Eyes
The robot dog features 8 dynamic action modes, including combat stance, stealth crawl, speed dash, handstands, and spins. These modes are often accompanied by three interactive sound effects. The RGB LED eyes can change colors, adding to the robot's expressive capabilities.
Baxım
- Təmizləmə: Wipe the robot dog and controllers with a soft, dry cloth. Do not use water or chemical cleaners.
- Batareyaya qulluq:
- Always remove batteries if the toy will not be used for an extended period.
- Batareyaları sərin, quru yerdə saxlayın.
- Batareyaları həddindən artıq temperaturlara və ya birbaşa günəş işığına məruz qoymayın.
- Dispose of depleted batteries responsibly according to local regulations.
- Yaddaş: Store the robot dog and its accessories in a clean, dry environment away from direct sunlight and extreme temperatures.
Problemlərin aradan qaldırılması
| Problem | Mümkün Səbəb | Həll |
|---|---|---|
| Robot dog does not turn on. | Batareya azdır və ya düzgün quraşdırılmayıb. | Charge the robot dog's battery. Ensure the battery is inserted with correct polarity. |
| Remote control or wristband not responding. | Controller batteries are low or not paired. | Replace batteries in the remote control. Ensure both the robot dog and controller are powered on and within range for pairing. |
| Robot dog moves erratically or not as expected. | Interference or low battery. | Ensure no other 2.4GHz devices are causing interference. Recharge the robot dog's battery. |
| Sound effects or LED eyes not working. | Function not activated or low battery. | Press the correct function button on the remote. Recharge the robot dog's battery. |
Spesifikasiyalar
- Məhsul Ölçüləri: 9.84 x 6.29 x 6.69 düym
- Maddə çəkisi: 1.9 funt sterlinq
- Model nömrəsi: OYUNCAQ2503
- İstehsalçı tərəfindən tövsiyə olunan yaş: 6 - 18 il
- Batareyalar: 2 Litium-ion batareyalar (daxildir)
- Nəzarət Tezliyi: 2.4 GHz
- İstehsalçı: SIMREX
Zəmanət və Dəstək
For warranty information and customer support, please refer to the official SIMREX websaytına daxil ola və ya birbaşa müştəri xidmətləri ilə əlaqə saxlaya bilərsiniz. Həmçinin ziyarət edə bilərsiniz SIMREX Store on Amazon for more product details and contact options.
