1. Giriş
This manual provides instructions for the assembly, operation, and maintenance of your Pinmoco Upgraded Cross-Legged Office Chair, Model L501681C. This ergonomic chair is designed to support various sitting postures, including cross-legged, to promote comfort and circulation during extended periods of use. It features adjustable components to suit individual preferences and is constructed with durable materials for long-lasting performance.
Figure 1: Pinmoco Upgraded Cross-Legged Office Chair in use.
2. Quraşdırma və Quraşdırma
The Pinmoco Cross-Legged Office Chair is designed for straightforward assembly. Please ensure all components are present before beginning. Refer to the included assembly diagram for detailed steps. If any parts are missing or damaged, please contact customer support.
- Komponentləri qablaşdırmadan çıxarın: Carefully remove all parts from the packaging and lay them out on a clean, flat surface. Verify against the parts list in your packaging.
- Təkərləri bazaya bərkidin: Insert the five casters into the holes at the end of each leg of the chair base until they click securely into place.
- Qaz Liftinin Quraşdırılması: Qaz qaldırıcı silindrini stulun əsas hissəsinin mərkəzi dəliyinə yerləşdirin.
- Assemble Seat and Backrest: Attach the backrest to the seat mechanism using the provided screws. Ensure all screws are tightened securely.
- Ayaq dayağını əlavə edin: Secure the footrest to its designated support structure, then attach this assembly to the main seat mechanism.
- Oturacağı Qaz Liftinə Qoşun: Carefully place the assembled seat onto the gas lift cylinder, ensuring it is centered and stable.
Figure 2: Product dimensions for assembly and space planning.
3. Əməliyyat və Tənzimləmələr
Your Pinmoco chair offers several adjustments to optimize your comfort and posture.
- Hündürlük tənzimlənməsi: Use the lever located under the seat on the right side to adjust the chair's height. Lift the lever while seated to lower, or lift the lever while standing to raise the chair.
- Arxalığın tənzimlənməsi: The backrest features a 2-level adjustable height mechanism. Loosen the knob or lever at the back of the chair, adjust the backrest to your desired height, and then tighten to secure. This allows for personalized lumbar support.
- 360 dərəcə fırlanma: Both the upper cushion and the footstool are designed to rotate 360 degrees, providing flexibility for various sitting positions and easy movement around your workspace.
- Footstool Usage: The extra-wide footstool is designed to support your legs, knees, and ankles when sitting cross-legged or in other alternative postures. Its height can be adjusted relative to the main seat from 0 to 4.7 inches, offering greater freedom to find a comfortable position.
Figure 3: Backrest adjustment and 360-degree rotation features.
Şəkil 4: Məsələnample of a meditation posture supported by the chair.
Figure 5: Detail of the extra-wide and thick seat and footrest for enhanced comfort.
4. Baxım və qulluq
Proper care will extend the life and appearance of your Pinmoco office chair.
- Təmizləmə: The chair is upholstered with PU leather, which is easy to clean and waterproof. For general cleaning, wipe the surface with a soft, damp cloth. For tougher spots, use a mild soap solution and wipe dry immediately. Avoid harsh chemicals or abrasive cleaners.
- Kaster Baxımı: Periodically check the casters for accumulated dust or hair and clean them to ensure smooth rolling.
- Avadanlıq yoxlanışı: Every few months, inspect all screws and bolts to ensure they are tight. Re-tighten if necessary to maintain stability and safety.
Figure 6: The chair's PU leather is designed for easy cleaning and water resistance.
5. Giderme
Kreslonuzla bağlı hər hansı bir problemlə qarşılaşsanız, xahiş edirik aşağıdakı ümumi həllərə müraciət edin:
- Kreslo cığıltısı: Check all bolts and screws and tighten them. Applying a small amount of silicone lubricant to moving parts (e.g., gas lift, tilt mechanism) may also help.
- Hündürlüyü tənzimləməkdə çətinlik: Ensure the height adjustment lever is fully engaged or disengaged. If the gas lift is unresponsive, it may require replacement.
- Təkərlər rəvan yuvarlanmır: Remove any debris (hair, lint) from the caster wheels. If casters are damaged, they may need to be replaced.
- Missing Parts or Bent Components: If you discover missing parts or a bent bar during assembly or use, please contact Pinmoco Direct customer service for assistance.
6. Spesifikasiyalar
| Xüsusiyyət | Detal |
|---|---|
| Brend | Pinmoco |
| Model Adı | L501681C |
| Rəng | Qara |
| Məhsul Ölçüləri | 15"D x 20"W x 38.6"H |
| Ölçü | Curved Shape |
| Arxa Stil | Çarpaz geri |
| Vahid sayı | 1.0 sayı |
| Maksimum Çəki Tövsiyəsi | 385 funt sterlinq |
| Nümunə | Möhkəm |
| Yaş Aralığı (Təsvir) | Yetkin |
| Daxil olan komponentlər | Basic Components of Chair |
| Forma | L şəklindədir |
| Qol Stili | Silahsız |
| Daxili / Xarici İstifadə | Daxili |
| Oturacaq dərinliyi | 15 düym |
| Doldurma materialı | Yaddaş köpüyü |
| Ayaq tərzi | Təkərlər |
| Maddə Çəkisi | 29.1 funt sterlinq |
| İlk Əlçatan Tarix | 18 fevral 2022-cü il |
7. Zəmanət və Dəstək
Pinmoco is committed to providing quality products and customer satisfaction. While specific warranty details are not provided in this manual, Pinmoco offers support services for its products.
If you encounter any issues such as missing parts, bent components, or require assistance with assembly or operation, please contact Pinmoco Direct customer service. They are available to provide parts replacement or upgrade services as needed.
Əlavə yardım üçün müraciət edin Pinmoco Store on Amazon or refer to your purchase documentation for contact information.
8. Məhsul Videoları
Bu təlimatda yerləşdirmək üçün satıcının heç bir rəsmi məhsul videosu mövcud deyil.
